| HP Z2 G8 Specifications |
| Available Operating Systems | Windows 10 Pro 64 – HP recommends Windows 10 Pro Windows 10 Pro 64 High End Windows 10 Pro 64 Workstations Plus Windows 10 Home 64 Plus Windows 10 Home 64 Advanced Linux® Ready Ubuntu 20.04 LTS |
| Processor family | Processor family 11th Generation Intel® Core™ i7 processor; 11th Generation Intel® Core™ i5 processor; 11th Generation Intel® Core™ i9 processor; 11th Generation Intel® Xeon® processor |
| Available processors | Intel® Core™ i9-11900K with Intel® UHD Graphics 750 (3.5 GHz base frequency, up to 5.3 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology |
| Intel® Core™ i9-11900F (2.5 GHz base frequency, up to 5.2 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores) |
| Intel® Core™ i9-11900 with Intel® UHD Graphics 750 (2.5 GHz base frequency, up to 5.2 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology |
| Intel® Core™ i7-11700K with Intel® UHD Graphics 750 (3.6G Hz base frequency, up to 5.0 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology |
| Intel® Core™ i7-11700 with Intel® UHD Graphics 750 (2.5 GHz base frequency, up to 4.9 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology |
| Intel® Core™ i5-11600K with Intel® UHD Graphics 750 (3.9 GHz base frequency, up to 4.9 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores), supports Intel® vPro® Technology |
| Intel® Core™ i5-11600 with Intel® UHD Graphics 750 (2.8 GHz base frequency, up to 4.8 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores), supports Intel® vPro® Technology |
| Intel® Core™ i5-11500 with Intel® UHD Graphics 750 (2.7 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores), supports Intel® vPro® Technology |
| Intel® Core™ i5-11400F (2.6 GHz base frequency, up to 4.4 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores) |
| Intel® Core™ i5-11400 with Intel® UHD Graphics 730 (2.6 GHz base frequency, up to 4.4 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores) |
| Intel® Xeon® W-1390 with Intel® UHD Graphics P750 (2.8 GHz base frequency, up to 5.2 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology |
| Intel® Xeon® W-1370P with Intel® UHD Graphics P750 (3.6 GHz base frequency, up to 5.2 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology |
| Intel® Xeon® W-1370 with Intel® UHD Graphics P750 (2.9 GHz base frequency, up to 5.1 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology |
| Intel® Xeon® W-1350P with Intel® UHD Graphics P750 (4.0 GHz base frequency, up to 5.1 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores), supports Intel® vPro® Technology |
| Intel® Xeon® W-1350 with Intel® UHD Graphics P750 (3.3 GHz base frequency, up to 5.0 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores), supports Intel® vPro® Technology |
| Intel® Xeon® W-1390P with Intel® UHD Graphics P750 (3.5 GHz base frequency, up to 5.3 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology |
| Chipset | Intel W580 |
| Form factor | Tower |
| Maximum memory | 128 GB DDR4-3200 ECC SDRAM; 128 GB DDR4-3200 non-ECC SDRAM Transfer rates up to 3200 MT/s. |
| Memory slots | 4 DIMM |
| Internal storage | 500 GB up to 2 TB 7200 rpm SATA HDD |
| 1 TB up to 8 TB 7200 rpm Enterprise SATA HDD |
| 500 GB 7200 rpm SED HDD |
| 256 GB up to 2 TB PCIe® NVMe™ TLC M.2 SSD |
| 256 GB up to 2 TB HP Z Turbo Drive PCIe® NVMe™ TLC M.2 SSD |
| 256 GB up to 2 TB HP Z Turbo Drive PCIe® NVMe™ SED Opal 2 TLC M.2 SSD |
| Optical drive | HP Slim DVD-ROM; HP Slim DVD-Writer |
| Available Graphics | Integrated: Intel® UHD Graphics 730; Intel® UHD Graphics 750; Intel® UHD Graphics P750 |
| Discrete: AMD Radeon™ Pro WX 3200 (4 GB GDDR5 dedicated); NVIDIA® Quadro® P620 (2 GB GDDR5 dedicated); NVIDIA® Quadro® P1000 (4 GB GDDR5 dedicated); NVIDIA® Quadro® P2200 (5 GB GDDR5 dedicated); NVIDIA® Quadro RTX™ 3000 (6 GB GDDR6 dedicated);NVIDIA® Quadro RTX4000 (8 GB GDDR6 dedicated); NVIDIA® Quadro RTX™ A4000 (16 GB GDDR6 dedicated); NVIDIA® Quadro RTX™ A5000 (24 GB GDDR6 dedicated) |
| Audio | Realtek ALC3205-VA2-CG, 2.0W internal mono speaker |
| Expansion slots | 1 PCIe 3 x4 (x16 connector); 1 PCIe 3 x4 (x4 connector); 1 M.2 2230 PCIe 3 x1; 1 PCIe 4 x16; 1 M.2 2280 PCIe 4 x4; 1 M.2 2280 PCIe 3 x4; 1 PCIe 3 x1 (x1 connector) (1 M.2 2230 slot for WLAN and 2 M.2 2280 slots for storage) |
| Ports and Connectors | Front: 2 SuperSpeed USB Type-A 10Gbps signaling rate; 1 universal audio jack; 2 SuperSpeed Type-A USB 5Gbps signaling rate (1 charging); 1 Type-C SuperSpeed® USB 20Gbps signaling rate (1 charging) |
| Rear: 1 audio-out; 1 RJ-45; 2 DisplayPort™ 1.4; 2 SuperSpeed USB Type-A 10Gbps signaling rate; 1 SuperSpeed USB Type-A 5Gbps signaling rate; 3 USB Type-A 480Mbps signaling rate |
| Optional Ports | Flex IO – choose one of the following options: 1 DisplayPort™ 1.4, 1 HDMI 2.0b, 1 VGA,1 2nd 1GbE LAN, 1 Dual SuperSpeed USB Type-A 5Gbps signaling rate,1 SuperSpeed USB Type-C® 10Gbps signaling rate (15W USB Power Delivery, |
| Alt Mode DisplayPort™) 1 Thunderbolt™ 3 with SuperSpeed USB4 Type-C® 40Gbps signaling rate (cabled to PCIe® AIC); Front – 1 SD card reader; Rear – 1 serial |
| Available Keyboards | HP USB Premium keyboard; HP Premium Wireless keyboard; HP Wireless Business Slim Keyboard and mouse combo; HP USB Business Slim SmartCard CCID Keyboard; HP Wired Desktop 320MK Mouse and Keyboard; HP Wired Desktop 320K Keyboard |
| Available Pointing Devices | HP USB Premium Mouse; HP Wireless Premium Mouse; HP Wired 320M Mouse |
| Communications | Intel® I219-LM GbE |
| Intel® I350-T2 dual-port GbE NIC |
| HP 10 GbE SFP+ SR Transceiver |
| Intel® X710-DA2 dual-port 10GbE SFP+ NIC |
| Aquantia AQN-108 1-port 5GbE NIC |
| Intel® Ethernet Network Adapter I225-T1 |
| Intel® X550-T2 dual-port 10GbE NIC |
| Intel® Wi-Fi 6 AX201 (2×2) and Bluetooth® 5 combo |
| Drive Bays | One 3.5″ HDD; One slim ODD; Two M.2 NVME 2280 SSD; One 2.5″ HDD; One 3.5″ HDD |
| Software | HP PC Hardware Diagnostics UEFI; HP Performance Advisor; HP Support Assistant; HP PC Hardware Diagnostics Windows; ZCentral Remote Boost; HP Desktop Support Utilities; HP Image Assistant; HP Notifications; My HP; HP QuickDrop |
| Security management | HP Secure Erase; HP Power On Authentication; HP Sure Click; Windows Defender; HP Sure Sense; HP BIOSphere Gen6; HP Client Security Manager Gen7; HP Sure Start Gen7; HP Sure Run Gen4; HP Sure Recover Gen4 |
| Security Software Licenses | HP Pro Security Edition (select models) |
| Management features | HP Driver Packs; HP Management Integration Kit for Microsoft System Center Configuration Management Gen4; HP System Software Manager (download); HP BIOS Configuration Utility (download) |
| Energy efficiency compliance | ENERGY STAR® certified; EPEAT® Gold registered in US |
| Power | 500 W 92% efficient, wide-ranging, active PFC; 7000 W 90% efficient, wide-ranging, active PFC |
| Dimensions | 14 x 6.7 x 15.2 in; 35.6 x 16.9 x 38.5 cm (Standard desktop orientation) |
| Sustainable impact specifications | Ocean-bound plastic in speaker enclosure; 45% post-consumer recycled plastic; 25% ITE-derived closed loop plastic; Bulk packaging available; 80 Plus® Gold power supplies available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable |
| Compatible displays | All HP Z Displays and HP DreamColor Displays are supported |
